JBF National neodymium diametric disc and cylinder magnets are crafted from the highest quality rare earth neodymium. These magnets are utilized across a wide spectrum of industries for a multitude of uses. To ensure longevity and maximum protection from corrosion, these magnets come triple coated with a base and top finish layer of nickel, with a layer of copper in between. Also, the holes these magnets feature make affixing them in place as needed, no issue at all.
JBF National Part Number | Description | Outer Dia. | H | Center Hole Dia. | Grade | Pull Strength Lbs. |
---|---|---|---|---|---|---|
1NDCRH-1349 | Diametrically Magnetized 3/4 in x 3/4 in Cylinder w/Hole Neo Magnets | 0.75 | 0.75 | 0.25 | N42 | 47 |
1NDCRH-1350 | Neodymium Magnets N48 3/4 in OD x 1/4 in ID x 3/4 in Rare Earth Disc | 0.75 | 0.75 | 0.25 | N48 | 56 |
2NDCRH-1351 | Neodymium Magnets 7/8 in x 7/8 in Cylinder w/3/16 in Hole | 0.88 | 0.88 | 0.19 | N42 | 73 |
3NDCRH-1352 | Neodymium Magnets 1 in x 1 in with 1/4 in Hole Cylinder | 1.00 | 1.00 | 0.25 | N42 | 95 |
3NDCRH-1353 | Neodymium Magnet 1 in x 1 in with 1/4 in Hole Diametrically Magnetized | 1.00 | 1.00 | 0.25 | N42 | 60 |
4NDCRH-1354 | N42 Neodymium Magnets 1.5 in x 1/4 in Disc w/hole | 1.50 | 0.25 | 0.25 or 0.19 | N42 | 36 |
4NDCRH-1355 | N45 Neodymium Disk Magnets 1.5 in x 1/2 in with 1/4 in hole | 1.50 | 0.50 | 0.25 | N45 | 72 |
5NDCRH-1356 | Neodymium Magnets 2 in x 1/2 in Disc with 3/16 in Hole Rare Earth | 2.00 | 0.50 | 0.19 | N42 | 110 |
5NDCRH-1357 | Rare Earth Magnets 2 in x 1 in with 1/4 in Hole Neodymium Disc N42 | 2.00 | 1.00 | 0.25 | N42 | 200 |
5NDCRH-1358 | Rare Earth Magnets N45 2 in x 2 in with 1/4 In Hole Neodymium Disc | 2.00 | 2.00 | 0.25 | N45 | 400 |
6NDCRH-1359 | Neodymium Magnets 3 in x 1/2 in with 1/4 in Hole Disc Strong N42 | 3.00 | 0.50 | 0.25 | N42 | 165 |
6NDCRH-1360 | Neodymium Magnets 3 in x 1 in Disc with 1/4 in Hole | 3.00 | 1.00 | 0.25 | N42 | 300 |
